UNKNOWN UNKNOWN Air Bag For Sale

$117

Description

AIR SPRING / AIR BAG Top Plate has Only One 3/4-16 Airlet Hole and no Blind Holes If You Need the 2 Blind Holes Try AB1DK23I-9579 Type Rolling Lobe Automann Bellows# 1DK23I Firestone Bellows# 1T15M-4/1T15VP-4 Goodyear Bellows# 566-24-3-076/566-26-3-053 Contitech Bellows# 9 10-13.5/9 10-14 Triangle Bellows# 6362/85/88 Bottom Plate Type A Top Plate Hole/Stud Qty 1 Top Plate Dia. (A) 9.00 Top Plate C to C Dia. (B) N/A Bottom Plate Hole/Stud Qty 4 Bottom Plate Dia. (C) 9.50 Bottom Plate C to C Dia. (D) 2.25 Bottom Part # BS09758 Bottom Plate Alignment Parallel Bumper Yes Bracket N/A Min. Height 5.5 Max. Height 17.7 Max. Dia. 12.6 WHERE USED This item is featured in the following schematics: NAME TYPE Hendrickson Turner Trailer HT190T, 230T, 250T, 300T, HT Dolly Suspension Hendrickson Turner Trailer HT190U, 250U, 250US, 300U Suspension APPLICATIONS There is no application data for this product. CROSS REFERENCE NAME PART NUMBER NOTES Firestone 9270 Air Spring Rolling Lobe Goodyear 1R13119 Air Spring Rolling Lobe Goodyear 1R13-119 Air Spring Rolling Lobe Hendrickson C20010 Air Spring Rolling Lobe Hendrickson C25559 Air Spring Rolling Lobe Hendrickson S25559 Air Spring Rolling Lobe Hendrickson/Turner S20010 Air Spring Rolling Lobe

Specifications
